ND100-2 Sample Concentrator

ND100-2 Sample Concentrator

ND100-2 sample concentrator is with microprocessor controlled and PID fuzzy controlled technique. Instead of traditional water bath device, the heat-conducting medium is high purity aluminum. The Test tubes are held in block, and blowing a large number of
Send Inquiry

Sample ConcentratorND100-2

Description:

ND100-2 sample concentrator is with microprocessor controlled and PID fuzzy controlled technique. Instead of traditional water bath device, the heat-conducting medium is high purity aluminum. The Test tubes are held in block, and blowing a large number of samples at one time.

 It can used in residue analysis, commodity inspection, food, environment, pharmacy and biological product and other industries.



Features:

1. High precision and wide range of temp. control.

2. Blowing a large number of samples at a time.

3. Blowing each sample independently.

4. Amount of airflow can be adjusted.

5. Easy operation; safe and reliable to use.


Applications:

Analysis of pesticide residues: vegetables, fruits, cereals, plant tissue.

Environmental analysis: such as drinking water, groundwater and polluted water samples.

Biological analysis: such as hormone analysis, sample preparation of liquid phase and gas phase and mass spectrometry analysis.

Food and beverage: such as milk, wine, beer, etc.

Pharmaceutical drug testing: such as traditional Chinese medicine pharmaceutical, drug screening.



Parameters:

Project

Parameters

 Temp range

 RT.+5°C -160°C

 Temp accuracy

 ±0.5℃(@40℃)

 Temp accuracy

 ±1℃(@120℃)

 Temp uniformity

 ±0.5℃

Display accuracy

0.1℃

Time Range

1-99h59min/∞

Heating time

≤15min(from 25℃ to 160℃

Needle length

150mm

Max gas usage

15L/min

Max gas pressure

0.02Mpa(Gas pin≤16pcs)

0.05Mpa(Gas pin1pcs)

Block qty

2

Max power

500W

Voltage

AC220V or AC110V /50~60Hz

Size

260 x 220 x 450mm

Weight

7.5kg





Optional Blocks:

Model

Tube diameter

Tube quantity

MD03

10mm

24

MD04

12mm

24

MD05

13mm

24

MD06

15mm

16

MD07

16mm

16

MD08

19mm

12

MD09

20mm

12

MD10

26mm

8

MD11

28mm

4

MD12

40mm

3

MD15

1.5ml centrifuge tube

24

MD16

2.0ml centrifuge tube

24
