TGL20 Table Top High Speed Refrigerated Centrifuge
TGL20 Table Top High Speed Refrigerated Centrifuge
Features:
1. Digital display indicates the speed,time,temperature and RCF.
2. Brushless DC motor in great torque, free maintenance,no powder pollution.quick in speed up and down.
3. There are many kinds of rotors for choice.
4. Automatically electric lid lock,super speed,over temperature protection and imbalance protection.
5. The centrifuge body is made of high-quality steel,safe and reliable.
TGL20 Technical Parameters | |||
Max Speed | 21000r/min | Max Volume | 6×100ml |
Timer | 1~99h59min | Dimension | 570×620×380mm |
Speed Accuracy | ±20r/min | Max RCF | 30910×g |
Noise | ≤58dBA | Net Weight | 84KG |
Power supply | AC 220V, 50HZ 10A | Temperature Range | -20℃~40℃ |
Temperature Accuracy | ±1℃ | ||
Order no | Rotor | Max Speed(r/min) | Volume(ml) | Max RCF(*g) |
G20-1 | Fixed Rotor | 16000 | 4×8PCR | 15760 |
G20-2 | Fixed Rotor | 15000 | 6×8PCR | 21420 |
G20-3 | Fixed Rotor | 16000 | 8×8PCR | 17480 |
G20-4 | Fixed Rotor | 15000 | 12×8PCR | 22930 |
G20-5 | Fixed Rotor | 21000 | 12×1.5/2ml | 30910 |
G20-6 | Fixed Rotor | 15000 | 40×0.5ml | 22920 |
G20-7 | Fixed Rotor | 17000 | 24×1.5/2ml | 26460 |
G20-8 | Fixed Rotor | 13500 | 30×1.5/2ml | 19340 |
G20-9 | Fixed Rotor | 13000 | 48×1.5/2ml | 17930 |
G20-10 | Fixed Rotor | 16000 | 16×5ml | 22020 |
G20-11 | Fixed Rotor | 16000 | 6×10ml | 21500 |
G20-12 | Fixed Rotor | 15000 | 12×10ml | 22680 |
G20-13 | Fixed Rotor | 16000 | 12×7ml | 21380 |
G20-14 | Fixed Rotor | 13000 | 16×10ml | 19490 |
G20-15 | Fixed Rotor | 10000 | 12×15ml | 11840 |
G20-16 | Fixed Rotor | 13000 | 8×15ml(falcon) | 17790 |
G20-17 | Fixed Rotor | 5000 | 24×15ml | 3500 |
G20-18 | Fixed Rotor | 15000 | 8×20ml | 22680 |
G20-19 | Fixed Rotor | 5000 | 30×15ml | 3830 |
G20-20 | Fixed Rotor | 14000 | 6×30ml | 19060 |
G20-21 | Fixed Rotor | 13000 | 6×50ml(falcon) | 18840 |
G20-22 | Fixed Rotor | 13000 | 6×50ml(round) | 18730 |
G20-23 | Fixed Rotor | 13000 | 4×85ml | 18940 |
G20-24 | Fixed Rotor | 12000 | 6×70ml | 15570 |
G20-25 | Fixed Rotor | 12000 | 4×100ml | 14850 |
G20-26 | Fixed Rotor | 12000 | 6×100ml | 16390 |
G20-27 | Fixed Rotor | 12000 | 24 pieces capillary vessel | 15800 |
G20-28 | Fixed Rotor | 18000 | 30×0.5ml | 26660 |
G20-29 | Swing Rotor | 13000 | 4×5ml | 14960 |
G20-30 | Vertical Rotor | 16000 | 16×5ml | 16540 |
G20-31 | Vertical Rotor | 14000 | 8×30ml | 16450 |
G20-32 | Microplate Rotor | 4000 | 2×3×48（well） | 2300 |
